Comparison of Steinmann Pin and Polymethyl Methacrylate Pin in Experimental Fractures of Humerus in Pigeon Models

Document Type : Research Article

Authors

• Alireza Kaveh Aski ¹
• Mohammad Mahdi Molaei ²
• Omid Azari ³
• Reza Kheirandish ⁴
• Dariush Vosough ²

¹ Post Graduate Student of Veterinary Surgery, Faculty of Veterinary Medicine, Shahid Bahonar University of Kerman , Kerman, Iran.

² Department of Clinical Science, Faculty of Veterinary Medicine, Shahid Bahonar University of Kerman , Kerman, Iran.

³ Department of Surgery & Radiology, Faculty of Veterinary Medicine, University of Tehran, Tehran, Iran.

⁴ Department of Pathobiology, Faculty of Veterinary Medicine, Shahid Bahonar University of Kerman, Kerman, Iran.

10.22067/ijvst.2024.88431.1388

Abstract

Avian orthopedic issues, particularly fractures, pose significant challenges due to birds' unique skeletal anatomy. Their bones, including the humerus (upper wing bone), are often pneumatic (air-filled) and fragile, making fracture management complex. Traditional methods, such as intermedullary pins and plates offer some solutions but have limitations. This study investigated the efficacy of two pin materials for stabilizing humerus fractures in pigeons: Steinman pins (commonly used in veterinary orthopedics) and polymethyl methacrylate (PMMA) pins. We created controlled fractures in the humerus of thirty young adult pigeons. These fractures were then stabilized with either Steinman pins or PMMA pins. Radiographic examinations and histological analysis were performed 2, 4, and 6 weeks post-surgery to assess bone healing progress in both groups. The findings revealed comparable healing outcomes between the two pin types, suggesting that PMMA pins could be a viable alternative for stabilizing fractures in birds, offering the additional benefit of sparing them a second surgery for pin removal.

Keywords

• Orthopedic
• bone cement
• bird
• wing

Main Subjects

• Surgery

---

References

1. Martin H, Ritchie BW. Orthopedic surgical techniques. Avian Medicine: Principles and Application Lake Worth, FL: Wingers Publishing. 1994;1(1):37-1169.
2. Carrasco DC. Fracture management in avian species. Veterinary Clinics: Exotic Animal Practice. 2019;22(2):223-38. https://doi.org/10.1016/j.cvex.2019.02.002
3. Bennett RA, Kuzma AB. Fracture management in birds. Journal of Zoo and Wildlife Medicine. 1992:5-38.
4. Westfall M, Egger E. The management of long bone fractures in birds. 1979.
5. Wimsatt J, Dressen P, Dennison C, Turner AS. Ultrasound therapy for the prevention and correction of contractures and bone mineral loss associated with wing bandaging in the domestic pigeon (Columba livia). Journal of Zoo and Wildlife Medicine. 2000;31(2):190-5. Doi:10.1638/1042-7260(2000)031[0190:UTFTPA]2.0.CO;2.
6. Bennert BM, Kircher PR, Gutbrod A, Riechert J, Hatt J-M. Evaluation of two miniplate systems and figure-of-eight bandages for stabilization of experimentally induced ulnar and radial fractures in pigeons (Columba livia). Journal of avian medicine and surgery. 2016;30(2):111-21.  Doi:10.1647/2015-082.
7. Tunio A, Jalila A, Goh YM. Histologic evaluation of critical size defect healing with natural and synthetic bone grafts in the pigeon (Columba livia) ulna. Journal of avian medicine and surgery. 2015;29(2):106-13. Doi:10.1647/2013-047
8. Wan PY, Adair HS, Patton CS, Faulk DL. Comparison of bone healing using polydioxanone and stainless steel intramedullary pins in transverse, midhumeral osteotomies in pigeons (Columba livia). Journal of Zoo and Wildlife Medicine. 1994:264-9.
9. Doneley B. Avian medicine and surgery in practice: companion and aviary birds: CRC press; 2016. Doi:10.1201/9781315371047.
10. Mathews K, Wallace L, Redig P, Bechtold J, Pool R, King V. Avian fracture healing following stabilization with intramedullary polyglycolic acid rods and cyanoacrylate adhesive vs. polypropylene rods and polymethylmethacrylate. Veterinary and Comparative Orthopaedics and Traumatology. 1994;7(04):158-69.  DOI:10.1055/s-0038-1633090.
11. Nazhvani SD, Etemadi F, Mohammadi M, Nazhvani FD. Humeral fracture treatment in pigeons by bone pins made from ovine and canine bones. Heliyon. 2019;5(11). Doi:10.1016/j.heliyon.2019.e02679.
12. Underwood W, Anthony R. AVMA guidelines for the euthanasia of animals: 2020 edition. Retrieved on March. 2020;2013(30):2020-1.
13. Christen C, Fischer I, von Rechenberg B, Flückiger M, Hatt J-M. Evaluation of a maxillofacial miniplate compact 1.0 for stabilization of the ulna in experimentally induced ulnar and radial fractures in pigeons (Columba livia). Journal of Avian Medicine and Surgery. 2005;19(3):185-90. Doi:10.1647/2004-010.1.
14. Eastaugh-Waring S, Joslin C, Hardy J, Cunningham J. Quantification of fracture healing from radiographs using the maximum callus index. Clinical Orthopaedics and Related Research®. 2009;467(8):1986-91. Doi:10.1007/s11999-009-0775-0.
15. Abrantes AAA, Rafacho A, Rivero ERC, Mariano FV, Siqueira FM, Gondak RO. Tissue integrity, costs and time associated with different agents for histological bone preparation. Microscopy research and technique. 2017;80(4):344-9. Doi:10.1002/jemt.22798.
16. Huang T-H, Tang C-H, Chen H-I, Fu W-M, Yang R-S. Low‐Intensity Pulsed Ultrasound‐Promoted Bone Healing Is Not Entirely Cyclooxgenase 2 Dependent. Journal of Ultrasound in Medicine. 2008;27(10):1415-23. Doi:10.7863/jum.2008.27.10.1415.
17. Bush M, Montali R, Novak G, James A, Jr. The healing of avian fractures: a histological xeroradiographic study. 1977.
18. West P, Rowland G, Budsberg S, Aron D. Histomorphometric and angiographic analysis of bone healing in the humerus of pigeons. American journal of veterinary research. 1996;57(7):1010-5.Doi:10.2460/ajvr.1996.57.07.1010.
19. YAMAZOE K, HIBINO C, KUDO T, YANAI T. The reduction of humeral fracture in pigeons with intramedullary poly (methyl methacrylate) and neutralization plate fixation. Journal of Veterinary Medical Science. 1994;56(4):739-45. Doi:10.1292/jvms.56.739.
20. Bush RM. External fixation of avian fractures. Journal of the American Veterinary Medical Association. 1977.
21. Wander KW, Schwarz PD, James SP, Powers BE, Taylor B, Wimsatt JH. Fracture healing after stabilization with intramedullary xenograft cortical bone pins: a study in pigeons. Veterinary Surgery. 2000;29(3):237-44. Doi:10.1053/jvet.2000.5608.
22. Hatt JM, Christen C, Sandmeier P. Clinical application of an external fixator in the repair of bone fractures in 28 birds. Veterinary Record. 2007;160(6):188-94. Doi:10.1136/vr.160.6.188.
23. KAYIKCI C, KUŞCU Y, DURMUŞ A, ASLAN L. Fractures and treatment methods in wild avians. Van Veterinary Journal. 2019;30(2):115-9.
24. Jang J-h, Lee M-h, Park Y-s, Kim M-j, Yun Y-m. Surgical Repair of Proximal Humeral Fracture in Common Kestrel (Falco tinnunculus). Journal of veterinary clinics. 2018;35(2):46-9. Doi:10.17555/jvc.2018.04.35.2.46.
